| CARACTERÍSTICAS DE HARDWARE | |
|---|---|
| Tipo de ficha | EU, UK, US |
| Protocolos e Normas | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Interface | 1 x 10/100/1000M Ethernet Port (RJ45) |
| Botão | WPS Button, Reset Button, LED Button, Power Button |
| Consumo de energia | 12W（max power consumption） |
| Dimensões (L x P x A) | 6.4 x 3.4 x 1.6 in. (163 x 86 x 40mm) |
| Antena | 4 x external |
| FUNCIONALIDADES WI-FI | |
|---|---|
| Frequências | 2.4GHz & 5GHz(11ac) |
| Signal Rate | 5GHz:Up to 1733Mbps 2.4GHz:Up to 800Mpbs |
| Reception Sensitivity | 5GHz： 11a 6Mbps:-96dBm@10% PER 11a 54Mbps: -78dBm@10% PER 11ac HT20 mcs8: -69dBm@10% PER 11ac HT40 mcs9: -66dBm@10% PER 11ac HT80 mcs9: -63dBm@10% PER 2.4GHz 11g 54M: -79dBm@10% PER 11n HT20 mcs7: -77dBm@10% PER 11n HT40 mcs7: -74dBm@10% PER |
| Modos Wireless | Range Extender/Access Point |
| Funções Wireless | Wireless Statistic Concurrent Mode boost both 2.4G/5G WiFi band Access Control LED Control Domain Login Function |
| Segurança Wireless | 64/128-bit WEP WPA-PSK / WPA2-PSK |
| Transmission Power | <20dBm(2.4GHz) <23dBm(5GHz) |
| OUTROS | |
|---|---|
| Certificações | CE, FCC, RoHS |
| Conteúdo da embalagem | AC2600 Wi-Fi Range Extender RE650 Quick Installation Guide |
| Dimensões da Caixa (L x P x A) | 7.9 x 4.9 x 3.8 in. (202 x 125 x 97mm) |
| Requisitos de Sistema | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
